Technical Specifications

Model		PC360-11M0 (Standard Spec.)	PC360-11M0 (SE Spec.)
Operating Weight	kg	34460	34460
Total Power	kW(PS)	202.3 (275)	202.3 (275)
Bucket Capacity	m³	1.60	1.90
Max. Travel Speed	High Speed (km/h)	5.5	5.5
	Medium Speed (km/h)	4.5	4.5
	Low Speed (km/h)	3.2	3.2
Max. Bucket Digging Force	kN	228	259
Max. Arm Digging Force	kN	171	201
Overall Length	mm	11150	10710
Overall Width	mm	3190	3190
Overall Height (to cab top)	mm	3160	3160
Max. Digging Height	mm	9925	9525
Max. Dumping Height	mm	7040	6575
Max. Digging Depth	mm	7380	6310
Max. Vertical Digging Depth	mm	6040	5625
Max. Digging Radius	mm	11080	10065
Max. Digging Radius at Ground Level	mm	10890	9860
Engine Model	–	SAA6D114E-6	SAA6D114E-6
Rated Engine Speed	rpm	1950	1950
Engine Displacement	L	8.85	8.85
