Technical Specifications

Item	Unit	Data
Operating Weight	kg	36600
Total Engine Power	kW	202.3
Total Hybrid Power	kW	235
Bucket Capacity	m³	1.90-2.30
Performance	–	–
	–	–
	–	–
Max. Travel Speed (High)	km/h	5.5
Max. Travel Speed (Medium)	km/h	4.5
Max. Travel Speed (Low)	km/h	3.2
Max. Bucket Digging Force	kN	241
Max. Arm Digging Force	kN	183
Dimensions	–	–
	–	–
	–	–
Overall Length	mm	11180
Overall Width	mm	3190
Overall Height (to Cab Top)	mm	3145
Working Range	–	–
	–	–
	–	–
	–	–
	–	–
	–	–
Max. Digging Height	mm	9975
Max. Dumping Height	mm	6820
Max. Digging Depth	mm	7145
Max. Vertical Digging Depth	mm	4925
Max. Digging Radius	mm	10905
Max. Digging Radius at Ground Level	mm	10715
Engine	–	–
	–	–
	–	–
Model	–	Komatsu SAA6D114E-6
Rated Speed	rpm	1950
Displacement	L	8.85

Product Performance

Energy-saving, Environmentally Friendly and Efficient New Power System

Komatsu new-generation non-road China IV emission standard engine
Komatsu hybrid system
Fuel efficiency improved by 38% ★
Automatic idle stop function

Efficient Operational Performance

Operational efficiency improved by 25% ★

Reliability and Durability

Reinforced working equipment
Reinforced overall superstructure
Double-flange idlers
Self-discharging air pre-filter
Large fuel filter
Coolant filter

Safe and Comfortable Operating Environment

ROPS cab (Roll-Over Protective Structure)
Automatic locking function for safety lock lever
Engine emergency stop switch
Large floating adjustable seat
Standard machine surrounding view system
Large anti-fall safety railing
