Product Details

Total Machine Weight
2050kg
Bucket Capacity
0.04m³
Power
18/2200kW/rpm

Applicable working conditions

Farmland renovation
Garden landscaping
Municipal utilities

Core Configuration

Power System

Equipped with a high-torque permanent magnet synchronous motor, achieving an output efficiency of up to 95%. The coordinated control of electric drive and hydraulic system ensures fast response, high operational precision, and smoother operation.It is equipped with a customized all-in-one integrated controller, featuring highly integrated circuitry and an auxiliary pre-charging function at power-on, resulting in a compact size and high integration level.A large-capacity lithium-ion battery, developed in-house, offers advantages such as high power density, safety and reliability, and intelligent fault diagnosis. It provides a continuous working time of 4-6 hours on a single charge.

Hydraulic System

It is equipped with a high-spec MVP30 main pump, featuring constant pressure variable and load-sensing functions. Its displacement performance is outstanding among products of the same tonnage, delivering smoother, more responsive, and better-coordinated operations.A Walvoil (沃尔福) hydraulic control multi-way valve is adopted to control all actuators. It is better suited for Chinese working conditions, with minimal pressure loss and low energy consumption.

Performance parameters

Item	Unit	Value
Operating Weight	kg	2050
Bucket Capacity	m³	0.04
Gradeability	% / °	47.5 / 21.4
Swing Speed	rpm	10
Ground Pressure	kPa	28
Bucket Digging Force	kN	13.2
Arm Digging Force	kN	12
Travel Speed	km/h	3.2 / 2.3
Track Shoe Width	mm	230
Track Rollers per Side	pcs	3
Carrier Rollers	pcs	2
Hydraulic Oil Tank Capacity	L	20
Radiator Capacity	L	4.9
Power Type	–	Permanent Magnet Synchronous Motor
Rated Power	kW/rpm	18/2200
Maximum Torque	N·m	138
Displacement	/L	–

Product Selling Points

Permanent Magnet Synchronous Motor: High power density, high torque density, high efficiency, safe and reliable, low energy consumption
Integrated Controller: Equipped with a customized all-in-one integrated controller, highly integrated circuit design, electric drive MCU function, three-phase AC charging OBC function, low-voltage power supply DCDC function, vehicle control VCU function, power-on precharge ancillary functions
Long-Lasting Range: Single charge driving range of 4-6 hours
Charging Modes: Household electricity, industrial electricity, vehicle charging piles, battery replenishment vehicles
Operating Modes: Supports both pure electric and extended electric dual modes
High Efficiency and Energy Saving: Higher efficiency than fuel versions, lower energy consumption than fuel versions
Safe and Reliable: Safety construction meets the safety level of new energy vehicles without blind spots
Clean and Environmentally Friendly: Pure electric, zero emissions, optional maintenance-free shaft sleeves
Comfort and Technology: 7-inch touch control screen, integrated button operation panel, AC slow charging and DC fast charging capabilities, redesigned pedal layout, cabin noise reduced to 66 decibels
Low Maintenance Costs: Pure electric power requires only hydraulic system maintenance, reducing maintenance expenses
