Product Details

Total Machine Weight
31,500 kg
Bucket Capacity
1.8 m³
Power
210/1900 kW/rpm

Applicable working conditions

Earthwork Engineering
Rockworks Engineering
Mining
Railway/Tunnel Construction
Excavation of Foundations

Power System

Equipped with an Isuzu 6HK1 engine with a rated power of 210kW, it boasts large displacement and torque, delivering robust and powerful performance.The turbocharger is upgraded to a VGT (Variable Geometry Turbocharger), featuring a shorter response time and reduced fuel consumption loss.

Hydraulic System

The pump displacement is increased from 160cc to 180cc, delivering a significant boost in flow capacity.Fully electronic control hydraulic technology is adopted to improve operational coordination and grading performance.The swing reducer is upgraded to an RG23 model, enhancing swing capacity and accelerating swing startup speed.

Performance parameters

Item	Unit	Value
Operating Weight	kg	31500
Bucket Capacity	m³	1.8
Rated Power	kW/rpm	210/1900
Overall Length (Transport)	mm	10700
Overall Width	mm	3190
Overall Height (Transport)	mm	3470
Upper Width	mm	2998
Overall Height (Cab Top)	mm	3280
Standard Track Shoe Width	mm	600
Track Gauge	mm	2590
Wheelbase	mm	–
Minimum Ground Clearance	mm	550
Tail Swing Radius	mm	3316
Track Ground Contact Length	mm	3915
Counterweight Clearance	mm	–
Track Length	mm	4840
Dozer Blade Width	mm	–
Travel Speed (High/Low)	km/h	5.7 / 3.3
Swing Speed	rpm	9
Gradeability	% / °	70 / 35
Ground Pressure	kPa	60.3
Bucket Digging Force	kN	204
Arm Digging Force	kN	153
Max Digging Height	mm	10500
Max Dumping Height	mm	7360
Max Digging Depth	mm	6815
Max Digging Radius	mm	4000
Max Straight Arm Digging Depth	mm	10870
Max Ground Digging Radius	mm	–
Max Digging Reach	mm	–
Max Height at Min Swing Radius	mm	–
Max Vertical Digging Depth	mm	–
Minimum Swing Radius	mm	8405

Product Selling Points

1. New Power
· Excellent power system, equipped with the Isuzu 6HK1 engine, rated power 210kW, large displacement and torque, strong power;
· Adopts fully electronic hydraulic technology, improving coordination and leveling performance.

2. New Technology
· New bucket upgrade, standard with rock bucket, achieving ‘one condition, one bucket’, optimizing bucket shape, improving excavation efficiency;
· Uses direct power control technology, dynamically adjusting according to load, reducing waste, and achieving energy saving.

3. New Design
· 10-inch large screen upgraded again, high system integration, and equipped with a wireless LAN inside the vehicle;
· Equipped with a new air conditioning system, smaller in size and stronger cooling effect;
· Interior fully upgraded, narrow armrest box, minimalist front control box, standard cup holder, 24V power outlet, USB interface, etc., featuring automotive-grade quality interior;
· Exterior upgraded, raised cover panel design, strengthened side doors, engine hood and toolbox lid use gas springs to assist, making opening more effortless.
