Product Details

Total Machine Weight
3780 kg
Bucket Capacity
0.12 m³
Power
20.2/2200 kW/rpm

Applicable working conditions

Farmland Renovation
Landscape Greening
Municipal Utilities
Trenching

Core Configuration

Power System

Equipped with a Sany-customized Yanmar 3TNV88 engine, it meets China National Stage IV (China IV) emission standards, delivering robust performance, high efficiency, and reliable durability.Engine Advantages: Widely applied in mini excavators with high customer recognition. It is durable, fuel-efficient, and easy to maintain.

Hydraulic SystemIt is equipped with a Sany-customized pump and valve system, developed and designed according to customer requirements. It features outstanding advantages such as high reliability, low pressure loss, and smooth combined operations.

Performance parameters

Item	Unit	Value
Operating Weight	kg	3780
Bucket Capacity	m³	0.12
Gradeability	%	58
Swing Speed	rpm	10
Ground Pressure	kPa	33-35
Bucket Digging Force	kN	30.4
Arm Digging Force	kN	18.2
Travel Speed	km/h	4.2 / 2.4
Track Shoe Width	mm	300
Track Rollers per Side	pcs	4
Carrier Rollers per Side	pcs	1
Track Plates per Side	pcs	44
Fuel Tank Capacity	L	50
Hydraulic Oil Tank Capacity	L	40
Engine Oil Capacity	L	6
Radiator Capacity	L	3.8
Final Drive Capacity (per side)	L	2×0.7
Engine Model	–	Yanmar 3TNV88
Rated Power	kW/rpm	20.2/2200
Maximum Torque	N·m	104.5
Displacement	L	1.642

Product Selling Points

1. Equipped with a Yanmar 3TNV88 engine, compliant with National IV emission standards, ensuring strong power output and reliable durability.
2. Tri-customized pump valve system, developed and designed according to customer needs, featuring outstanding advantages such as high reliability, low pressure loss, and smooth compound operations.
3. Standard dual-direction auxiliary circuit, allowing the selection of various attachments according to actual requirements, easily handling conditions such as digging, grabbing, unloading, drilling, cutting, and crushing.
