Product Details

Total Machine Weight
95000 kg
Bucket Capacity
5.5-8 m³
Power
574/2100 kW/rpm

Applicable working conditions

Earth and rock engineering
Rock engineering
Mining

Power System

Equipped with a Scania DC16 engine with a rated power of 574kW, it delivers powerful performance to meet the high-load requirements of mining operations.By eliminating DPF and SCR after-treatment systems, there is no DPF regeneration and no need for urea addition, making operation convenient and significantly reducing operating costs.

Hydraulic System

Equipped with a fully electronic hydraulic system and large-displacement main pump, featuring pressure cut-off function to reduce overflow loss. The large-diameter electronically controlled parallel closed spool ensures low pressure loss and smooth operation coordination.

Full Electronic Control System

Adopts Full Electronic Integrated Control Technology (ICT), mainly including E-P, P-V, FD and ECA technologies, namely engine-main pump matching, main pump-main valve matching, flow distribution, electronic control assistance, boom gravity lowering, and independent oil and water cooling control.

Automatic Lubrication

Adopts an electric grease dispenser, which is easy to operate, labor-saving and time-efficient, avoids grease waste, and ensures the oil remains uncontaminated. It can be directly placed on the grease inside a standard finished oil drum, and grease injection is completed once powered on. This product has obtained a national utility model patent (Patent No.: 201922484372.7).

Performance parameters

Item	Unit	Value
Operating Weight	kg	95000
Bucket Capacity	m³	5.5-8.0
Power	kW/rpm	574/2100
Engine Model	–	Scania DC16
Engine Type	–	Direct Injection, 8-Cylinder 4-Stroke, Turbocharged Intercooled, Water-Cooled
Displacement	L	16.4
Maximum Torque	N·m/rpm	3260/1400
Rated Power	kW/rpm	574/2100
Travel Speed (High/Low)	km/h	4.3 / 3.0
Swing Speed	rpm	7
Gradeability	°	35
Ground Pressure	kPa	132
Bucket Digging Force	kN	495
Arm Digging Force	kN	469
Fuel Tank Capacity	L	1180
Engine Oil Capacity	L	50
Radiator Capacity	L	82
Final Drive Capacity (per side)	L	2×18
Track Plates	pcs	51
Track Rollers per Side	pcs	9
Carrier Rollers per Side	pcs	3
Standard Track Shoe Width	mm	650

Product Selling Points

1. Equipped with a Scania DC16 engine, rated power 574KW, providing strong power to meet the high-load demands of mining operations;

2. Complies with National III emission standards, without DPF and SCR after-treatment, eliminating the maintenance of after-treatment, making it worry-free and convenient;

3. Equipped with a fully electronically controlled hydraulic system, large displacement main pump with pressure cut-off function, reducing overflow loss. Large-diameter electronically controlled parallel closed center, low pressure loss, ensuring coordination;

4. Standard 6.5m³ large bucket, suitable for harsh and demanding mining environments, can be configured with 4 series of buckets, meeting the ‘one condition, one bucket’ requirement, improving construction efficiency, easily handling various complex working conditions, enhancing product value and customer profitability.
